Cruise 12.0 R TorqLink
- 12 kW continuous power - powerful propulsion like a 25 hp combustion engine
- TorqLink data interface - enables fast data exchange between TorqLink components without gateway
- Electric tilting device for comfortable operation
- Easy handling thanks to low-voltage design (48 volts)
- Very robust construction - corrosion-protected, seawater-proof and waterproof all around (IP67)
- Battery connection cable with water-protected battery pole terminals (IP 66) for connecting up to two Power 48-5000
- Variants: Short shaft S: 38.5cm shaft length, long shaft L 51.2cm shaft length, extra long shaft XL 63.9cm shaft length
- Weight (without cable & main switch): 59.8 kg (S), 61.3 kg (L), 62.5 kg (XL)
- To operate the Cruise 12.0 with more than two Power 48-5000 batteries, please contact your Torqeedo dealer
- Please note that the engine power is reduced to 6 kW when operating with only one Power 48-5000 battery
Cruise motors are the electric outboard motor of choice for motorboats, dinghies and commercial users. All Cruise systems have a built-in GPS with onboard computer and display with speed and input power, state of charge and remaining range, with a compact, low-drag, and lightweight pylon due to advanced helical gear design. Cruise 12.0 is a 48-Volt, 25 horsepower-equivalent outboard perfect for boats up to 10 tons. The Cruise 12.0 R ships with Torqeedo’s advanced communication system, TorqLink (see below for further information), which allows faster and more accurate data sharing between system components.
Cruise 12.0 R TorqLink - Benefits:
- High-efficiency outboard with 12,000 W input power, equivalent to a 25 HP petrol outboard
- Pair with two or more Power 48-5000 for best performance and accurate range/runtime functionality
- This model ships with remote steering link arm
- Your choice of TorqLink throttles (we recommend part number 1976-00 TorqLink throttle with colour display)
- Rugged aluminium pylon with integral fin – extra protection when running aground
- Highest-grade seawater-proof aluminium for long service life, even in the harshest conditions
- Comprehensive galvanic corrosion protection through careful matching of all materials and meticulous isolation of materials with different electrochemical properties - ships with anode set for fresh and saltwater
Technical Data Cruise 12.0 R TorqLink
| Cruise 12.0 R TorqLink |
|---|---|
| Input power in watts | 12,000 |
| Propulsive power in watts | 6720 |
| Comparable petrol outboards (propulsive power) | 25 CV |
| Comparable petrol outboards (thrust) | 25 CV |
| Maximum overall efficiency in % | 56 |
| Static thrust in lbs* | ≤ 405 |
| Integrated battery | - |
| Nominal voltage | 48 |
| Final charging voltage | - |
| Weight in kg (w/o cables & main switch) | 59.8 (S), 61.3 (L), 62.5 (XL) |
| Motor weight without battery in kg | - |
| Weight of integrated battery | - |
| Shaft length in cm | 38.5 (S) / 51.2 (L) / 63.9 (XL) |
| Standard propeller v = speed in km/h at p = power in watts | v22/p10k |
| Alternative propeller options | v32/p10k & v15/p10k |
| Maximum propeller speed in rpm | 1,400 |
| Control | Remote throttle |
| TorqLink | Yes |
| Steering | Provision to connect to standard remote steering |
| Tilting device | Electrohydraulic tilt device with overload protection. |
| Tilt angle | +-45° |
| Trim device | Manual, 4-step |
| Integrated on-board computer | Yes |
| Stepless forward/reverse drive | Yes |
* Torqeedo static thrust measurement is based on internationally accepted ISO standards. Static thrust figures for conventional trolling motors are typically measured differently, which results in higher values. To compare Torqeedo static thrust data with conventional trolling motors, add approximately 50% to the Torqeedo static thrust values.
- Optimised propeller design: for greater thrust or more speed
- Extremely robust design, suitable also for commercial use
- Available with short, long and extra long shaft
- Electric tilt for ease of operation
- Connection for standard remote steering
THE CRUISE FAMILY
Cruise 3.0 R
≡ 6 HP
Cruise 3.0 T
≡ 6 HP
Cruise 6.0 R TorqLink
≡ 9.9 HP
Cruise 6.0 T
≡ 9.9 HP
Cruise 10.0 T
≡ 20 HP
Cruise 12.0 R TorqLink
≡ 25 HP
